Drilling Rig Type and production scope
1. Cluster well rig and Baker Hughes Project
Single-way cluster drilling rig
Double-way cluster drilling rig
2. Solid moving rig
Trailer mounted rig
Fast moving drilling rig
Polar rig
3. Truck mounted drilling rig
4. Workover rig
5. Complete set of land drilling rig
6. Drilling Depth ｍ （ｆｔ） : ４０００－７０００m ( 13200-23000ft)
7. Max Hook Load Rating Kn(lbs): 2250-4500kN ( 500000-1000000lbs)
|
Drilling Depth |
7000m |
Drive ways |
VFD Drive |
Hook Block |
YC450,DG450 |
|
Max Hook Load(lbf) |
1011600 |
Transmission box model |
ZLQ70DB |
Swivel |
SL450 |
|
Hook Speed (ft/s) |
0~6 |
Traveling system |
7×6 |
Rotary Table |
ZP375 |
|
Mast Effective height(ft) |
148 |
Drawworks |
JC70DB |
Mud pump power (hp*set) |
1600×3 |
|
Mast Type |
K type |
Draw works power(hp) |
2000 |
Nominal working pressure of hydraulic system (psi) |
2000 |
|
Drill Floor Height (ft) |
35 |
Main Brake |
Disc brake |
Max working pressure of air system （psi） |
145 |
|
Substructure type |
Swing up |
Auxiliary Brake |
Motor resistance brake |
Engine type |
CAT3512B |
|
Engineer Power (hp*set) |
4×1757 |
Drilling Line Diameter(in) |
1 1/2 inch |
